UÇAK HİDROLİK SİSTEM EĞİTİM SETİ
UHT 100A UÇAK HİDROLİK SİSTEM EĞİTİM SETİ

Aircraft Hydraulic System Trainer provides students with practical experience needed to understand the function, to get to know components and to improve troubleshooting skills. Fully functional hydraulic system designed so that every component can be disassembled, reassembled and functionally tested.

All the components mounted on the trainer are operational, removable and they can be reinstalled.

Features:

  • Hydraulic control solenoids
  • Flap control
  • Speed Brake Control
  • Landing Gear Control
  • System is powered by Hydraulics Pump, Hand Pump or Accumulator.
  • All wires should be coded and labeled for troubleshooting.
  • The hardware used in the trainer is mounted to the frame in a way that it can be easily observable by students.
  • Instructor’s panel for Fault Insertion

Components:

  • Electrically Driven Hydraulic Pump
  • Hydraulics Filter
  • Landing gear control solenoid
  • Landing gear door control solenoid
  • Flap control solenoid
  • Speed Brake control solenoid
  • Emergency Hand Pump
  • Hydraulic Fluid Reservoir
  • Hydraulic Accumulator with automatic filling
  • Hydraulic System analog pressure gauge (8 pieces)
  • Pressure sender
  • Hydraulic System Pressure sender
  • Drain Valve
  • Check valve
  • Control Panel
  • Circuit brakers
  • Power Panel

  • ATA Chapters

    • The system mounted on a metal/aluminum mobile stand.
    • Metal/aluminum frame with 4 wheels. 2 of 4 wheels are lockable.
    • Training video for teachers
    • Delivered fully assembled tested and ready to operate
    • Colored Ultraviolet printing method on aluminum composite panel


    Documentation:

    • User’s Manual
    • Study Guide
    • Instructor’s Guide
    • Components Diagrams


    Power Specs

    • Electrical box
    • Residual current device
    • Emergency Button
    • Energy Signal Lamp
    • 110VAC 60 Hz or 220-240 VAC 50 Hz


    Dimensions and weight

    • Height: Width:    Depth:
