BUZ VE YAĞMUR KORUMASI&KONTROL SİSTEM SETİ
AID 100A BUZ VE YAĞMUR KORUMASI&KONTROL SİSTEM SETİ

AID-100A Ice and Rain Protection System Trainer offers opportunity to trainees to physically see various components and connections in between them in real-life like mechanism. It brings together all aspects of deicing and rain protection system on aircrafts. AID-100A is manufactured with authentic aircraft components. It is mounted on movable four-wheeled frame that can be positioned as necessary.

Features:

  • Understanding fundamentals of aircraft Ice & Rain Protection & Control System and its components.
  • Windshield heating system
  • Pitot tube heating system
  • The pitot tube is in a transparent protection area.
  • Propeller blade heating system
  • Slipring system for propeller principles is exhibited
  • Drain heating system
  • Pneumatic de-ice boot
  • Windshield wiper system
  • Windshield wiper is in a compartment with a transparent front part.
  • Windshield wiper is automatically spray alcohol to the surface.
  • Water in windshield wiper compartment is accumulate to alcohol tank through drain line.
  • The hose and tubes used in the trainer are labeled according to aviation standards.
  • Wirings on the trainer are connected via terminals.
  • Wires should have clear identification labels for each wire.
  • All wires should be coded and labeled for troubleshooting.
  • Instructor’s panel for Fault Insertion

Components:

  • Lower EICAS or ECAM
    • Bleed valve status
    • Bleed line pressure
    • Fuel flow indicator
    • Switch Position
    • Valve status
  • Bleed Control Panel
  • Windshield wiper control panel
    • Off position
    • Park position
    • Low and High position
    • The text on the panel should back lighted like in aircrafts, not printed or stickers.
    • Panel should be independent of other panels.
  • Window heat panel
  • Left side and forward control
  • Right side and forward control
  • The text on the panel should back lighted like in aircrafts, not printed or stickers.
  • Panel should be independent of other panels.
  • Wing and Engine Anti-Ice control panel
  • Windscreen Wiper
  • Windscreen Wiper motor/actuator
  • Windscreen Wiper Arm/blade
  • Aircraft Window with heating elements
  • Temperature control thermostat
  • Window heating timer control box
  • Windshield De-Icing Alcohol Dispensing
  • Alcohol Pump
  • Alcohol Tank
  • Sprayer
  • Pitot Tube with electrical heating elements
  • Pitot tube heating timer control box
  • Aircraft composite Propeller blade with electrical de-ice boot
  • Propeller heating timer control box
  • Propeller Slip-ring
  • Pneumatic De-Ice Boot
  • Pump for Pneumatic De-Ice Boot
  • Drain with heating elements

ATA Chapters

  • The system mounted on a metal/aluminum mobile stand.
  • Metal/aluminum frame with 4 wheels. 2 of 4 wheels are lockable.
  • Training video for teachers
  • Delivered fully assembled tested and ready to operate
  • Colored Ultraviolet printing method on aluminum composite panel

Documentation:

  • User’s Manual
  • Study Guide
  • Instructor’s Guide
  • Components Diagrams

Power Specs

  • Electrical box
  • Residual current device
  • Emergency Button
  • Energy Signal Lamp
  • 110C 60 Hz or 220-240 VAC 50 Hz

Dimensions and weight

  • Height: Width:    Depth:
